All copper bellows/Instrument brass bellow/copper tube

Large Image : All copper bellows/Instrument brass bellow/copper tube

Product Details:

Place of Origin:	china
Brand Name:	huaxing
Certification:	ISO9001

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	usd10.00
Packaging Details:	standard export packing
Delivery Time:	within 3 Days
Payment Terms:	T/T wire transfer
Supply Ability:	999999999999999

Contact Now

Detailed Product Description

All copper bellows/Instrument brass bellow/copper tube

Refrigeration Shock Tube / Vibration Absorber

http://www.hydraulichosecn.com

Introduction of Vibration Absorber

· Vibration absorbers are designed for installation in the suction and discharge lines of Air conditioning and Refrigeration system to dampen the transmission of compressor-induced vibration through system piping.
· Each unit is constructed of a deep pitch corrugated tubing for increased flexibility and vibration absorption, covered by a high tensile wire braid for superior strength.
· Tubing and braid are reinforced by ferrules at each end and connected to female copper tube ends by a high temperature braze alloy.

Features of Vibration Absorber

· Each unit securely brazed, pressure and vacuum tested, cleaned, dehydrated and sealed in plastic wrap
· Stainless steel corrugated tubing and high tensile wire braid
· Compatible with all HFC, HCFC and CFC refrigerants including R410A refrigerant
· UL approved and CE marked under the Pressure Equipment Directive(PED) 97/23/EC
· Available with Stainless steel tube ends for use with Ammonia NH3

Specification of Vibration Absorber

All copper bellows/Instrument brass bellow/copper tube

Material of Vibration Absorber

Description	Corrugated tube	Wired Braid	Grooved Ferrule	Ferrule	Tube Ends
Stainless steel Vibration Absorber	stainless Steel 304	Stainless Steel 304	Phosphor Bronze	Stainless Steel 304	Copper TP2
Copper Vibration Absorber	Bronze	Bronze	Phosphor Bronze	Copper TP2	Copper TP2
